12
Rockwell Automation Publication 2711PC-UM002B-EN-P - April 2014
Chapter 1
Overview
Software Support
lists software supported by the terminals.
Table 1 - PanelView Plus 6 Compact Software Support
PanelView Plus 6 Compact
Applications
PanelView Plus 6 Compact Machine Edition applications are restricted to a
subset of the functions on the PanelView Plus 6 terminals:
• Maximum of 25 screens.
• Maximum of 200 alarm messages.
• One connection or shortcut to a single controller by using either RSLinx
Enterprise or KEPServer Enterprise software.
• Only Serial and Ethernet communication are supported.
If using RSLinx Enterprise software, only serial DF1, serial DH-485, and
Ethernet drivers are supported.
Product Selections
lists the catalog numbers of the PanelView Plus 6 Compact terminals.
Software
Description
Version
FactoryTalk View Machine
Edition Station
Runtime environment for FactoryTalk View Machine Edition .mer
applications. Machine Edition Station is preloaded on each terminal
and does not require FactoryTalk View activation.
6.10 or later
FactoryTalk View Studio for
Machine Edition
Configuration software for developing HMI applications that run on
PanelView Plus 6 Compact terminals.
RSLinx
Enterprise software is included with FactoryTalk View Studio
software and loaded during installation.
6.10 or later
Windows CE 6.0
operating system
All terminals run the Windows CE 6.0 operating system with an open
or closed desktop environment. Other supported features include
these items:
• FTP server
• VNC client/server
• ActiveX controls
(1)
• Third-party device support
• Adobe PDF reader
(1) Refer to
Display FactoryTalk View ME Station Information on page 66
for a list of ActiveX controls loaded on a terminal.
6.0
Table 2 - PanelView Plus 6 Compact Terminals
Cat. Nos.
Display
Input Type
Communication
Ports
USB Ports
Power
Size
Type
Ethernet RS-232
Host
Device
2711PC-K4M20D8
3.5-in.
Grayscale
Keypad
•
•
•
•
DC
2711PC-B4C20D8
Color
Keypad and Touch
•
•
•
•
2711PC-B4C20D8-LR
•
•
•
•
2711PC-T6M20D8
5.7-in.
Grayscale
Touch
•
•
•
•
2711PC-T6C20D8
Color
•
•
•
•
2711PC-T10C4D8
10.4 in.
Color
Touch
•
•
•
•
