Chapter 6 Connections and Communication
Controller Connections Table 48 through Table 51 provides a summary of PanelView Plus 6
Compact connections to controllers and interface modules.
Table 48 - Communication Cables: PanelView Plus 6 Compact Terminals to SLC Controllers
Protocol PanelView Plus 6 Compact Port
SLC 500, 5/01, 5/02
CH1 RJ45
(DH-485)
SLC 5/03, 5/04, 5/05
CH0 (9-pin RS-232)
(DF1 or DH-485)
SLC 5/03
CH1 (RJ45)
(DH-485)
SLC 5/04
CH1 (DH+)
SLC 5/05
CH1 (ENET)
DF1
RS-232 (DF1) port (9-pin)
All terminals
—
2711-NC13 (5 m/16 ft)
2711-NC14 (10 m/32 ft)
— — —
DH-485
RS-232 (DH-485) port (9-pin)
All terminals
Use AIC+ module
(1761-NET-AIC) to connect to
port 1 or 2
2711-NC13 (5 m/16 ft)
2711-NC14 (10 m/32 ft)
Use AIC+ module
(1761-NET-AIC) to
connect to port 1 or 2
— —
DH-485 port
1000 terminals only
Requires 2711P-RN6, 2711P-RN6K
1761-CBL-AS03
(3 m/10 ft)
1761-CBL-AS09
(9 m/30 ft)
Use AIC+ module
(1761-NET-AIC)
to connect to port 3
1761-CBL-AS03
(3 m/10 ft)
1761-CBL-AS09
(9 m/30 ft)
— —
EtherNet/IP
EtherNet/IP port
All terminals
2711P-RN20 provides additional port -
1000 terminals only
—
Use 1761-NET-ENI module
with Ethernet cable
— —
1585J-M type cable or
2711P-CBL-EX04
(4 m/14 ft)
Table 49 - Communication Cables: PanelView Plus 6 Compact Terminals to PLC-5 and MicroLogix Controllers
Protocol PanelView Plus 6 Compact Port
PLC-5, PLC-5C, PLC-5E
CH0 (25-pin RS-232)
(DF1)
MicroLogix 1400, 1500LRP
CH1/CH2 (9-pin RS-232)
(DF1 or DH-485)
MicroLogix 1000, 1100, 1200,
1400, 1500LSP
CH0 (8-pin Mini DIN)
(DF1 or DH-485)
MicroLogix 1100, 1400
Ethernet
DF1
RS-232 (DF1) port (9-pin)
All terminals
2711-NC13 (5 m/16 ft)
2711-NC14 (10 m/32 ft)
(9-to-25 pin adapter required)
2711-NC13 (5 m/16 ft)
2711-NC14 (10 m/32 ft)
2711-NC21 (5 m/16 ft)
2711-NC22 (15 m/49 ft) (1)
—
DH-485
RS-232 (DH-485) port (9-pin)
All terminals
—
2711-NC13 (5 m/16 ft)
2711-NC14 (10 m/32 ft)
2711-NC21 (5 m/16 ft)
2711-NC22 (15 m/49 ft)
—
DH-485 port
1000 terminals only
Requires 2711P-RN6, 2711P-RN6K
—
—
Use AIC+ module
(1761-NET-AIC)
to connect to port 3
—
EtherNet/IP
EtherNet/IP port
All terminals
2711P-RN20 provides additional port -
1000 terminals only
To PLC-5E with
1585J-M type cable or
2711P- CBL-EX04 (4 m/14 ft)
Use 1761-NET-ENI module
with Ethernet cable
1585J-M type cable or
2711P- CBL-EX04 (4 m/14 ft) (1)
(1) The AIC+ module is recommended for isolation purposes when the terminal and controller are not on same power supply.
Table 50 - Communication Cables: PanelView Plus 6 Compact Terminals to Logix Controllers
Protocol PanelView Plus 6 Compact Port
ControlLogix
CH0 (9-pin RS-232)
(DF1)
CompactLogix
CH0 (9-pin RS-232)
(DF1 or DH-485)
DF1
RS-232 (DF1) port (9-pin)
All terminals
2711-NC13 (5 m/16 ft)
2711-NC14 (10 m/32 ft)
2706-NC13 (3 m/10 ft)
2711-NC13 (5 m/16 ft)
2711-NC14 (10 m/32 ft)
2706-NC13 (3 m/10 ft)
DH-485
RS-232 (DH-485) port (9-pin)
All terminals
— 2711-NC13 (5 m/16 ft)
2711-NC14 (10 m/32 ft)
2706-NC13 (3 m/10 ft)
DH-485 port
1000 terminals only
Requires 2711P-RN6, 2711P-RN6K
—
Use AIC+ module
(1761-NET-AIC)
Connect to Port 3
EtherNet/IP
EtherNet/IP port
All terminals
2711P-RN20 provides additional port -
1000 terminals only
Use 1756-EN2T or 1756-ENBT module with
1585J-M type cable or
2711P- CBL-EX04 (4 m/14 ft)
To 1769-L35E, 1769-L23E, 1769-L32E,
or 1768-ENBT module with 1585J-M type cable
or 2711P- CBL-EX04 (4 m/14 ft)
