Publication 2705-UM001A-EN-P
B-10 DeviceNet Information
Instance 2 Attributes (Discrete Output Number 2)
Common Services
Attribute
ID Access
Rule Name DeviceNet
Data Type Data Value
3 Get Output Value BOOL 0 = OFF
1 = ON
4 Get Status BOOL 0 = OK
1 = Fault
5 Get Fault State BOOL DIP Switch 9 defines:
0 = use fault value
1 = hold last state
6 Get Fault Value BOOL 0 (OFF)
7 Get Idle State BOOL 0 = use idle state
8 Get Idle Value BOOL 0 (OFF)
10 Get Flash Output BOOL 0 = no flash
1 = flash
11 Get Flash Rate USINT DIP Switch 10 defines:
0 (OFF) = 1 HZ
2 (ON) = 2 HZ
Service
Code
Implemented
Service
Class Instance
OE
hex
Yes Yes Get_Attribute_Single
