DeviceNet Information B-7
Common Services
1 For Class, resets all connections to nonexistent. For Instance, resets connection timer, and if applicable,
changes the state from timed out to established.
Assembly Objects Class Code: 04 Hex
Class Attributes
Number of Instances: 2
Instance 1 Attributes (Input Assembly)
1 Input Data: bit 0 = discrete input object instance 1, attribute 3 (input value)
bit 1 = discrete input object instance 2, attribute 3 (input value)
bit 2 = discrete input object instance 3, attribute 3 (input value)
bit 3 = discrete input object instance 4, attribute 3 (input value)
bit4 = discrete output object instance 1, attribute 4 (status)
bit 5 = discrete output object instance 2, attribute 4 (status)
bit 6,7 = undefined (0)
Instance 2 Attributes (Output Assembly)
2 Output Data: bit 0 = discrete output object instance 1, attribute 3 (output value)
bit 1 = discrete output object instance 1, attribute 10 (flash output)
bit 2 = discrete output object instance 2, attribute 3 (output value)
bit 3 = discrete output object instance 2, attribute 10 (flash output)
bit 4-7 = undefined (0)
Service
Code
Implemented
Service
Class Instance
O5
hex Yes Yes
Reset
1
OE
hex
Yes Yes Get_Attribute_Single
10
hex
No Yes Set_Attribute_Single
Attribute
ID Access
Rule Name DeviceNet
Data Type Data Value
1 Get Revision UINT 2
Attribute
ID Access
Rule Name DeviceNet
Data Type Data Value
3 Get Data Byte
Input_Data
1
Attribute
ID Access
Rule Name DeviceNet
Data Type Data Value
3 Get Data Byte
Output_Data
2
