5 - building a custom redistation, Chapter objectives, Custom build components – Rockwell Automation 2705 RediSTATION Operator Interface User Manual User Manual
Page 37: Building a custom redistation, Chapter objectives -1 custom build components -1, Chapter
1
Publication 2705-UM001A-EN-P
Chapter
5
Building a Custom RediSTATION
Chapter Objectives
This chapter describes how to create a RediSTATION.
Custom Build Components
RediSTATION components can be ordered separately and customer
installed. 800T operators and indicators must be purchased separately.
Section
Page
Custom Build Components
Operators and Indicators
Assembling the RediSTATION
Cover
with Gasket
Enclosure
Prewired DeviceNet Connector
or Conduit Hole
6 Cover
Mounting Screws
Circuit Board
2 Circuit Board
Mounting Screws
Circuit Board
Spacers (sizes
depend on device)
I/O Cables
DeviceNet
Terminal Block
