1-10 Overview of RediSTATION
Catalog Number
Configuration The following catalog number configuration shows how to order
standard or custom built RediSTATION units.
2 7 0 5 - T 3 D N 1 A 4 2 A - X X X X X
Bulletin Number
Custom Layout
See Publication 2705-3.3
Button Type:
T = 800T
Number of Operators:
3
Configuration Type:
A = Standard
1 Pilot Light
1 Start Button
1 Stop Button
X = Custom
Z = Unpopulated
Network Type:
DN = DeviceNet
Enclosure Type:
1 = Die Cast
DeviceNet Connector:
A = Sealed
B = Terminal Block
Board Type:
42 = 4 Inputs, 2 Outputs
