Publication 2705-UM001A-EN-P
Troubleshooting and Maintenance 4-5
Replacing a Pilot Lamp
Light Pilot light lamps can be replaced easily without opening enclosure.
To replace a pilot light lamp:
1. Remove lens cap from the pilot light.
2. Remove lamp from socket.
3. Carefully insert new lamp in socket.
4. Replace the lens cap.
5. Check for proper operation.
ATTENTION
!
To avoid electrical shock or unintended
operation of the equipment, remove power.
ATTENTION
!
Do not use a screwdriver or other metal object
to remove lamp.
ATTENTION
!
Before replacing the lens cap, be sure the lamp
is seated properly or a short may result.
