Common services, Discrete input objects, Class code: 08 hex – Rockwell Automation 2705 RediSTATION Operator Interface User Manual User Manual
Page 52: Class attributes, Number of instances: 4, Instance 1 attributes (discrete input number 1), Instance 2 attributes (discrete input number 2), Instance 3 attributes (discrete input number 3)
Publication 2705-UM001A-EN-P
B-8 DeviceNet Information
Common Services
Discrete Input Objects
Class Code: 08 Hex
Class Attributes
Number of Instances: 4
Instance 1 Attributes (Discrete Input Number 1)
Instance 2 Attributes (Discrete Input Number 2)
Instance 3 Attributes (Discrete Input Number 3)
Service
Code
Implemented
Service
Class
Instance
OE
hex
Yes
Yes
Get_Attribute_Single
Attribute
ID
Access
Rule
Name
DeviceNet
Data Type
Data Value
1
Get
Revision
UINT
2
Attribute
ID
Access
Rule
Name
DeviceNet
Data Type
Data Value
3
Get
Input Value
BOOL
0 = OFF
1 = ON
Attribute
ID
Access
Rule
Name
DeviceNet
Data Type
Data Value
3
Get
Input Value
BOOL
0 = OFF
1 = ON
Attribute
ID
Access
Rule
Name
DeviceNet
Data Type
Data Value
3
Get
Input Value
BOOL
0 = OFF
1 = ON
