Publication 2705-UM001A-EN-P
DeviceNet Information B-5
Connection Object Class Code: 05 Hex
Class Attributes
Number of Instances: 2
Instance 1 Attributes (Explicit Message Connection)
1 xxxxxx = node address
Attribute
ID Access
Rule Name DeviceNet
Data Type Data Value
1 Get Revision UINT 1
Attribute
ID Access
Rule Name DeviceNet
Data Type Data Value
1 Get State USINT 0 = nonexistent
3 = established
5 = deferred delete
2 Get Instance Type USINT 0 = explicit message
3 Get Transport Class Trigger USINT 83
hex
4 Get Produced Connection ID UINT
10xxxxxx011
binary
1
5 Get Consumed Connection ID UINT
10xxxxxx100
binary
1
6 Get Initial Comm
Characteristics USINT 21
hex
7 Get Produced
Connection Size UINT 7
8 Get Consumed
Connection Size UINT 7
9 Get/Set Expected Packet Rate UINT 2500 msec (default),
with time resolution
of 10 msec
12 Get/Set Watchdog Timeout Action USINT 1 = autodelete
(default)
3 = transitions to
deferred delete
13 Get Produced Connection
Path Length UINT 0
14 Get Produced Connection Path null (no data)
15 Get Consumed Connection
Path Length UINT 0
16 Get Consumed Connection Path null (no data)
