1
Publication 2705-UM001A-EN-P
Appendix
A
Specifications
Electrical
Mechanical
Supply Voltage
11 to 25V DC
Power Consumption
7 Watts Maximum
Inputs
Maximum Number
4
Type
Hard Contact Sourcing
Voltage/Current
24V DC/24mA Maximum
Isolation
None
Outputs
Maximum Number
2
Voltage/Current
24V DC/100mA Maximum
Isolation
None
Enclosure
NEMA Type 4, 12, 13
Weight
3.1 lbs (1.4 kg)
Dimensions
Inches
8.26 (H) x 3.81 (W) x 4.41 (D)
Millimeters
209.8 (H) x 96.8 (W) x 112.0 (D)
