5.11.6
Clearing a Trigger
You can remove a set trigger for a selected rung. Once the trigger is
removed, the rung's status area returns to the state it was in prior to
the trigger being set.
To clear a trigger
Step 1.
Select the rung or at least one instruction in the rung
containing the trigger you want to remove. See Selecting
Rungs," section 2.2, or Selecting Instructions," section
2.7, for more information.
Step 2.
From the Online menu, select Capture Trigger. Move the
mouse to the right to display the Capture Trigger menu.
Step 3.
From the Capture Trigger menu, choose Clear Trigger.
The Editor also clears triggers when the selected rung is scrolled
out of view on the screen or when an online program is closed.
5.12
Setting and Forcing Variables in Ladder
Programs
You can set and force variables in ladder programs to put them
temporarily in a known state for debugging purposes. To set, force,
and unforce variables, you must have an online program window
open. You can set or force any global variable in the configuration or
any local variable present in a task that is loaded into the rack.
I
MPORTANT
You can force only simple variables. You cannot force
elementĆindexed or bitĆindexed variables. For example, you cannot
force variables like: vat.13, array_var[11], array_var[index_name],
array_var[11].12, or array_var[index_name].bit_name.
WARNING
THE SET AND FORCE FUNCTIONS BYPASS CONTROL OF THE APPLICATION
PROCESS BY THE APPLICATION PROGRAMS. IT IS THE RESPONSIBILITY OF
THE USER TO DETERMINE THE POTENTIAL HAZARDS INVOLVED. FAILURE TO
OBSERVE THESE PRECAUTIONS COULD RESULT IN BODILY INJURY.
WARNING
VARIABLES AND OUTPUTS THAT ARE FORCED BEFORE AC POWER IS LOST
WILL REMAIN FORCED WHEN AC POWER IS RESTORED. SHOULD AC POWER
BE LOST WHILE VARIABLES ARE FORCED, THE USER MUST ENSURE THAT
UNEXPECTED MACHINE MOVEMENT DOES NOT OCCUR WHEN AC POWER IS
RESTORED. FAILURE TO OBSERVE THESE PRECAUTIONS COULD RESULT IN
BODILY INJURY.
