Page 42

3Ć8
3.7
Displaying and Printing Coils as
RightĆJustified
Use the Right Justify Coils after Verify feature to automatically move
coils to the right side of the printout so that you can more easily
read your program. If coils are not blocked by another instruction,
the Editor aligns them against the first vertical page break. Coils that
already extend past this page break are moved left and up. (They
are not moved to the next page break.)
To display and print programs with rightĆjustified coils
Step 1.
From the Tools menu, choose Options.
Step 2.
On the General Tab, choose Right Justify Coils after
Verify.
Step 3.
Click OK.
Coils are only moved out to the grid limit when the limit is to the left
of the first vertical page break.
The default option is not to rightĆjustify coils after verifying or printing
a program. The rungs are displayed and printed compressed up
and to the power rail when you verify or print the program.
3.8
Printing Multiple Copies of Programs
You can print more than one copy of a program at a time.
To print multiple copies of a program
Step 1.
Make sure that the program you want to print is in the
active program window.
Step 2.
Do one of the following:
D Click on
or
D From the File menu, choose Print
or
D Press CTRL+P
Step 3.
Within the Print dialog box, use the Copies spinner box to
enter or select the number of copies you want to print.
