DH/DH+ Error Codes
Appendix B
B-8
Error Code
Meaning
Associated
Commands
Error Type
236
reply
PLCĆ3 read
•
File not found.
•
Destination address does not have enough levels to specify a PLCĆ3 word (for
wordĆrange reads) or a file (for file reads).
•
The PLCĆ3 address specifies more levels than required.
•
Word specified by the PLCĆ3 address does not exist.
reply
PLCĆ3 bit write
•
File not found.
•
Destination address does not specify a PLCĆ3 word.
•
The PLCĆ3 address specifies more levels than required.
•
Word specified by the PLCĆ3 address does not exist.
reply
PLCĆ3 write
•
Destination file not found.
•
Destination address does not point to a word (for wordĆrange writes) or a file
(for file writes).
•
Destination address specifies more levels than required.
•
First word of destination location does not exist.
237
reply
PLCĆ3 read and
write
•
Any word in the total transaction does not exist in the destination file.
•
The source and destination files are not the same size.
238
reply
PLCĆ3 read and
write
The file size decreased between packets of a multiĆpacket transaction and
became too small for the total transaction.
239
reply
PLCĆ3 read and
write
File is larger than 65,535 words.
240
reply
PLCĆ3 read and
write
Sum of total transaction size and the word level of PLCĆ3 addressing is greater
than 65,535.
241
reply
PLCĆ3 write
Remote station does not have access to the destination file.
243
reply
all
•
No privilege for upload/download
•
Words already created or already deleted.
245
reply
restart
No previous shut down command received.
255
local
all
Module being sent message does not exist. Should also get BAD ADDRESS
major system fault.
