Rockwell Automation 1775-S5_SR5,D17756.5.5 User Manual PLC-3 FAMILY I/0 User Manual
Page 152

Binary Command Language
Appendix A
A-24
When the processor receives a read-modify-write command,
it (Figure A.3):
1.
Reads the data at the specified address.
2.
Performs a logical AND operation between the data read in step 1 and
the AND mask.
3.
Performs a logical OR operation between the result of step 2 and the
OR mask.
4.
Writes the result of step 3 into the word at the specified address.
Figure A.3
ReadĆModifyĆWrite Operation
Bit Pattern
Description
1111000011110000
Initial state of specified word
0101010101010101
AND mask
0101000001010000
Result of logicalĆAND operation
1010000001011111
Final result
The processor responds to a read-modify-write command with one of the
following response codes:
Response Codes
Hex
Description
00
Success
04
Address unknown
06
Access not allowed
08
Address not complete
0F
No privilege
The following response block shows a successful read-modify-write
command:
STX
02
OSC
01
SIZ
01
RSP
00
ETX
03
CHK
07
