Rockwell Automation Publication 1732E-UM005A-EN-E - July 2012 69
Appendix
A
Specifications
General Specifications The analog input and output modules, 1732E-IF4M12R and
1732E-OF4M12R, have the following general specifications.
Input Specifications The 1732E-IF4M12R module has the following input specifications.
General Specifications
Attributes Value
Voltage, power, max 30V DC
Voltage, power, min 12V DC
Module power 12…30V DC @ @ 150mA – 1732E-IF4M12R
12…30V DC @ @ 250mA – 1732E-OF4M12R
Power consumption 3 W @ 24V DC, typical
3.5 W, max (module unloaded)
Isolation voltage 50V (continuous), Basic Insulation Type
Type tested @ 707V DC for 60 s
Communication rate EtherNet/IP
10/100 Mbps
Full or half-duplex
100 meter per segment
Status indicators Module status – red/green
Network status – red/green
Link status – green/yellow
Auxiliary power status – green
I/O LED – red/green
Dimensions, approx., HxWxD 179 x 37 x 27 mm (7.05 x 1.46 x 1.06 in.)
Weight, approx. 0.34 kg (0.75 lb)
Wiring category (1)
(1) Use this Conductor Category information for planning conductor routing. Refer to publication 1770-4.1 ,
Industrial Automation Wiring and Grounding Guidelines.
1 – on signal ports
1 – on power ports
1 – on communication ports
Input Specifications – 1732E-IF4M12R
Attributes Value
Number of inputs 4
Resolution, min 16 bits
Data format 16-bit sign magnitude
Conversion rate 1.005 kHz per channel
Input type Configurable as voltage or current inputs
Notch Filter 1 kHz per channel
