Preface
Read this preface to familiarize yourself with the rest of the manual. It provides
information concerning:
• who should use this manual
• the purpose of this manual
• related documentation
• conventions used in this manual
Who Should Use this
Manual
Use this manual if you are responsible for designing, installing, programming, or
troubleshooting control systems that use 1732E ArmorBlock Dual Port
EtherNet/IP Dual-Port 4-Point Analog Input and Output Modules.
Purpose of this Manual
This manual is a reference guide for the 1732E-IF4M12R, 1732E-OF4M12R
modules. It describes the procedures you use to install, wire, configure,
troubleshoot, and use your module.
Related Documentation
The following documents contain additional information concerning Rockwell
Automation products. To obtain a copy, contact your local Rockwell Automation
office or distributor.
Common Techniques Used
in this Manual
The following conventions are used throughout this manual:
• Bulleted lists such as this one provide information, not procedural steps.
• Numbered lists provide sequential steps or hierarchical information.
• Italic type is used for emphasis.
Resource
Description
1732E ArmorBlock™ Dual-Port EtherNet/IP 4-Point Analog
Modules
Information on wiring the ArmorBlock Dual-Port EtherNet/IP 4-Point Analog
Modules (1732E-IF4M12R, 1732E-OF4M12R, 1732E-IT4IM12R,
1732E-IR4IM12R).
1732E ArmorBlock Dual-Port EtherNet/IP 4-Point Analog Input
and Output Installation Instructions, publication
Information on installing the ArmorBlock EtherNet/IP module.
EtherNet/IP Embedded Switch Technology Application Guide,
publication
A manual on how to install, configure and maintain linear and Device-level
Ring (DLR) networks using Rockwell Automation EtherNet/IP devices with
embedded switch technology.
EtherNet/IP Modules in Logix5000 Control Systems User
Manual, publication
A manual on how to use EtherNet/IP modules with Logix5000 controllers and
communicate with various devices on the Ethernet network.
Getting Results with RSLogix 5000™, publication
Information on how to install and navigate RSLogix 5000. The guide includes
troubleshooting information and tips on how to use RSLogix 5000 effectively.
Allen-Bradley Industrial Automation Glossary
A glossary of industrial automation terms and abbreviations.
