Chapter 5
Add, Configure, Monitor, and Replace CIP Safety I/O
Table 21 - Status Indicator Operation
Indicator
Status
Description
Guard I/O DeviceNet Modules
Guard I/O EtherNet/IP Modules
POINT Guard I/O Modules
Module
Status (MS)
Off
No power.
Green, On
Operating under normal conditions.
Green, Flashing
Device is idle.
Red, Flashing
A recoverable fault exists.
A recoverable fault exists or a firmware update is in progress.
Red, On
An unrecoverable fault exists.
Red/Green,
Flashing
Self-tests in progress.
Self-tests are in progress or the module is not configured properly. See the network status
indicator for more information.
Network
Status (NS)
Off
Device is not online or may not have power.
Green, On
Device is online; connections are established.
Green, Flashing
Device is online; no connections established.
Red, Flashing
Communication timeout.
Communication timeout or a firmware update is in progress.
Red, On
Communication failure. The device has detected an error that has prevented network communication.
Red/Green,
Flashing
Device is in Communication Faulted state or
safety network number (SNN) is being set.
Self-test in progress.
Not applicable.
Input Points
(INx)
Off
Safety input is OFF.
Yellow, On
Safety input is ON.
Red, On
An error has occurred in the input circuit.
Red, Flashing
When dual-channel operation is selected, an error has occurred in the partner input circuit.
Output Points
(Ox)
Off
Safety output is OFF.
Yellow, On
Safety output is ON.
Red, On
An error has occurred in the output circuit.
Red, Flashing
When dual-channel operation is selected, an error has occurred in the partner output circuit.
Test Output
Points (Tx)
Off
Not applicable.
The output is OFF.
Not applicable.
Yellow, On
The output is ON.
Red. On
An error has occurred in the output circuit.
LOCK
Yellow, On
Device configuration is locked.
The Logix Designer application does not support this function.
Yellow, Flashing
Device configuration is valid, but device is not
locked.
Yellow, Off
Invalid, no configuration data, or device has
been configured.
IN PWR
Green, Off
No input power.
Not applicable.
Green, On
Input power voltage is within specification.
Yellow, On
Input power voltage is out of specification.
OUT PWR
Green, Off
No output power.
Green, On
Output power voltage is within specification.
Yellow, On
Output power voltage is out of specification.
PWR
Green, Off
Not applicable.
No power.
Green, On
Power voltage is within specification.
Yellow, On
Power voltage is out of specification.
