Preface
Additional Resources
These documents contain additional information concerning related products
from Rockwell Automation.
You can view or download publications at
. To order paper copies of
technical documentation, contact your local Allen-Bradley distributor or
Rockwell Automation sales representative.
Table 3 - Publications Related to GuardLogix Controllers and Systems
Resource
Description
(Safety)
Application
requirements
GuardLogix 5570 Controller Systems Safety Reference Manual,
publication
Contains detailed requirements for achieving and maintaining SIL 3/PLe with the
GuardLogix 5570 controller system, using the Studio 5000 Logix Designer application.
GuardLogix Controller Systems Safety Reference Manual, publication
Contains detailed requirements for achieving and maintaining SIL 3/PLe with the
GuardLogix 5560 or 5570 controller system, using RSLogix 5000 software.
CIP Sync (time
synchronization)
Integrated Architecture and CIP Sync Configuration Application
Technique, publication
Provides detailed and comprehensive information about how to apply CIP Sync
technology to synchronize clocks in a Logix control system.
Guard I/O™
Guard I/O DeviceNet Safety Modules User Manual, publication
Provides information on using Guard I/O DeviceNet Safety modules.
Guard I/O EtherNet/IP Safety Modules User Manual, publication
Provides information on using Guard I/O EtherNet/IP Safety modules.
POINT Guard I/O Safety Modules User Manual, publication
Provides information on installing, configuring, and using POINT Guard I/O™
modules.
Hardware
installation
ControlLogix Chassis and Power Supplies Installation Instructions,
publication
Describes how to install and ground ControlLogix
®
chassis and power supplies.
Industrial Automation Wiring and Grounding Guidelines, publication
Provides in-depth information on grounding and wiring programmable controllers
Instructions
(programming)
GuardLogix Safety Application Instruction Set Reference Manual,
publication
Provides information on the GuardLogix Safety application instruction set.
Logix5000 Controllers General Instructions Reference Manual,
publication
Provides programmers with details about each available instruction for a Logix5000™
controller.
Logix5000 Controllers Motion Instructions Reference Manual, publication
Provides programmers with details about the motion instructions that are available
for a Logix5000 controller.
Motion
SERCOS Motion Configuration and Startup User Manual, publication
Details how to configure a SERCOS motion application system.
Motion Coordinated Systems User Manual, publicat
Details how to create and configure a coordinated motion application system.
CIP Motion Configuration and Startup User Manual, publicat
Details how to configure a Integrated Motion on EtherNet/IP networks application
system.
CIP Motion Reference Manual, publicat
Detailed information on axis control modes and attributes for Integrated Motion on
EtherNet/IP networks.
Networks
(ControlNet,
DeviceNet
EtherNet/IP)
EtherNet/IP Modules in Logix5000 Control Systems User Manual,
publication
Describes how to configure and operate EtherNet/IP modules in a Logix5000 control
system.
ControlNet Modules in Logix5000 Control Systems User Manual,
publicat
Describes how to configure and operate ControlNet modules in a Logix5000 control
system.
DeviceNet Modules in Logix5000 Control Systems User Manual,
publication
Describes how to configure and operate DeviceNet modules in a Logix5000 control
system.
PhaseManager™
PhaseManager User Manual, publicat
Provides steps, guidance, and examples for setting up and programming a Logix5000
controller to use equipment phases.
Programming
tasks and
procedures
Logix5000 Controllers Common Procedures Programming Manual,
publication
Provides access to the Logix5000 Controllers set of programming manuals, which
cover managing project files, organizing tags, ladder logic programming, testing
routines, creating Add-On Instructions, controller status data, handling faults,
importing and exporting project components and more.
Logix5000 Controllers Execution Time and Memory Use Reference
Manual, publication
Assists in estimating the memory use and execution time of programmed logic and in
selecting among different programming options.
