Store and Load Projects Using Nonvolatile Memory
Chapter 8
Loading a Safety Project
You can only initiate a load from nonvolatile memory, if the following is true:
• The controller type specified by the project stored in nonvolatile memory
matches the controller type.
• The major and minor revisions of the project in nonvolatile memory
matches the major and minor revisions of the controller.
• Your controller is not in Run mode.
You have several options for when (under what conditions) to load a project into
the user memory of the controller.
Use Energy Storage Modules
You can use the GuardLogix ESMs to execute either of the following tasks:
• Provide power to the controller to save the program to the controller’s on-
board non-volatile storage (NVS) memory after power is removed from
the chassis or the controller is removed from a powered chassis.
Table 35 - Options for Loading a Project
If you want to load the project
Then select this
Load Image
option
Notes
Whenever you turn on or cycle
power
On Power Up
• During a power cycle, you lose any online changes, tag values, and network schedule that you have not stored in the
nonvolatile memory.
• The controller loads the stored project and firmware at every powerup regardless of the firmware or application
project on the controller. The load occurs whether or not the controller is safety-locked or has a safety task signature.
• You can always use the Logix Designer application to load the project.
Whenever there is no project in the
controller and you turn on or cycle
chassis power
On Corrupt Memory
• For example, if the battery becomes discharged and the controller loses power, the project is cleared from memory.
When power is restored, this load option loads the project back into the controller.
• The controller updates the firmware on the primary controller or the safety partner, if required. The application
project stored in nonvolatile memory is also loaded and the controller enters the selected mode, either Program or
Run.
• You can always use the Logix Designer application to load the project.
Only through the Logix Designer
application
User Initiated
• If the controller type as well as the major and minor revisions of the project in nonvolatile memory match the
controller type and major and minor revisions of the controller, you can initiate a load, regardless of the Safety Task
status.
• Loading a project to a safety-locked controller is allowed only when the safety task signature of the project stored in
nonvolatile memory matches the project on the controller.
• If the signatures do not match or the controller is safety-locked without a safety task signature, you are prompted to
first unlock the controller.
IMPORTANT: When you unlock the controller and initiate a load from nonvolatile memory, the safety-lock status,
passwords, and safety task signature are set to the values contained in nonvolatile memory once the load is
complete.
• If the firmware on the primary controller matches the revision in nonvolatile memory, the safety partner firmware is
updated, if required, the application stored in nonvolatile memory is loaded so that the Safety Task status becomes
Safety Task Operable and the controller enters the selected mode, either Program or Run.
IMPORTANT
Before using ControlFLASH software, make sure the SD card is unlocked if set to
load On Power Up. Otherwise the updated data may be overwritten by
firmware on the memory card.
IMPORTANT
When you are using an ESM to save the program to on-board NVS
memory, you are not saving the program to the SD card installed in the
controller.
