Appendix A
Status Indicators
The latter part of the format, #XXXX message, can be used to diagnose the type
of I/O fault and potential corrective actions. For details about each I/O fault
code, see the Logix5000 Major, Minor, and I/O Fault Codes Programming
Manual, publication
.
Table 49 - I/O Fault Messages
Code
Message
Code
Message
#0001
Connection Failure
#0115
Wrong Device Type
#0002
Insufficient Resource
#0116
Wrong Revision
#0003
Invalid Value
#0117
Invalid Connection Point
#0004
IOI Syntax
#0118
Invalid Configuration Format
#0005
Destination Unknown
#0119
Module Not Owned
#0006
Partial Data Transferred
#011A
Out of Connection Resources
#0007
Connection Lost
#0203
Connection Timeout
#0008
Service Unsupported
#0204
Unconnected Message Timeout
#0009
Invalid Attribute Value
#0205
Invalid Parameter
#000A
Attribute List Error
#0206
Message Too Large
#000B
State Already Exists
#0301
No Buffer Memory
#000C
Object Mode Conflict
#0302
Bandwidth Not Available
#000D
Object Already Exists
#0303
No Bridge Available
#000E
Attribute Not Settable
#0304
ControlNet Schedule Error
#000F
Permission Denied
#0305
Signature Mismatch
#0010
Device State Conflict
#0306
CCM Not Available
#0011
Reply Too Large
#0311
Invalid Port
#0012
Fragment Primitive
#0312
Invalid Link Address
#0013
Insufficient Command Data
#0315
Invalid Segment Type
#0014
Attribute Not Supported
#0317
Connection Not Scheduled
#0015
Data Too Large
#0318
Invalid Link Address
#0100
Connection In Use
#0319
No Secondary Resources Available
#0103
Transport Not Supported
#031E
No Available Resources
#0106
Ownership Conflict
#031F
No Available Resources
#0107
Connection Not Found
#0800
Network Link Offline
#0108
Invalid Connection Type
#0801
Incompatible Multicast RPI
#0109
Invalid Connection Size
#0802
Invld Safety Conn Size
#0110
Module Not Configured
#0803
Invld Safety Conn Format
#0111
RPI Out of Range
#0804
Invld Time Correct Conn Format
#0113
Out of Connections
#0805
Invld Ping Intrvl EPI Multiplier
#0114
Wrong Module
#0806
Time Coord Msg Min Multiplier
