Publication 1769-UM009E-EN-P - August 2009

99

DeviceNet I/O Image Chapter 6

Fault

This bit displays whether the network is faulted.

• 0 = Network is not faulted
• 1 = Network is faulted

Disable Network

This bit displays whether the network is disabled.

• 0 = Network is not disabled
• 1 = Network is disabled

Device Failure

This bit displays whether any device failures have occurred on the network.

• 0 = No device failures exist
• 1 = Device failure exists (examine the status structure for causes)

Autoverify Failure

This bit displays whether the scanner has failed to initialize any devices on the
network.

• 0 = The scanner has initialized all devices
• 1 = The scanner has failed to initialize at least one device

Comm Failure

This bit displays whether a communication failure exists on the network.

• 0 = No communication failures exist
• 1 = A communication failure exists
