Chapter
2
Quick Start for Experienced Users
Introduction
This chapter helps you get started using the 1769-SDN scanner module.
Procedures are based on the assumption that you have an understanding of
Rockwell Automation controllers. You should understand electronic process
control and be able to interpret the ladder logic instructions required to
generate the electronic signals that control your application. Because it is a
start-up guide for experienced users, this chapter does not contain detailed
explanations about the procedures listed.
Required Tools and
Equipment
Have the following tools and equipment ready:
• Personal computer
• Programmable controller: CompactLogix or MicroLogix 1500 system
• 1770-KFD RS-232 DeviceNet adapter or 1784-PCIDS, 1784-U2DN
DeviceNet interface card
• For network communication: RSLinx software, version 2.30 or later
• For DeviceNet network configuration:
–
RSNetWorx for DeviceNet software, version 3.00 or later
• For ladder logic programming:
–
RSLogix 500 programming software, version 5.00.10 or later, or
–
RSLogix 5000 programming software, version 8.02 or later
• 1769-SDN scanner module
• Mounting hardware
• Screwdriver
Topic
Page
