Slave device idle array – Rockwell Automation 1769-SDN Compact I/O DeviceNet Scanner Module User Manual User Manual
Page 90

90
Publication 1769-UM009E-EN-P - August 2009
Chapter 6 DeviceNet I/O Image
Slave Device Idle Array
The slave device idle array contains 64 bits of data. Each bit indicates the state
of a slave device. A bit value of 0 represents a Non-idle mode or that the slave
is not present in the scanlist. A bit value of 1 represents Idle mode where the
slave node is present in the scanlist.
Slave Device Configuration Comparison to Scanner Module Configuration
Input Word
Bit 0...15
Description
6
(1)
(1)
Bit 0 corresponds to Node 0, Bit 1 corresponds to Node 1 … Bit 15 corresponds to Node 15.
Node 0…15
Bit ON (1) = Slave node mismatch
Bit OFF (0) = Slave node match
7
(2)
(2)
Bit 0 corresponds to Node 16, Bit 1 corresponds to Node 17 … Bit 15 corresponds to Node 31.
Node 16…31
8
(3)
(3)
Bit 0 corresponds to Node 32, Bit 1 corresponds to Node 33 … Bit 15 corresponds to Node 47.
Node 32…47
9
(4)
(4)
Bit 0 corresponds to Node 48, Bit 1 corresponds to Node 49 … Bit 15 corresponds to Node 63.
Node 48…63
Slave Device Status
Input Word
Bit 0...15
Description
10
(1)
(1)
Bit 0 corresponds to Node 0, Bit 1 corresponds to Node 1 … Bit 15 corresponds to Node 15.
Node 0...15
Bit ON (1) = Idle
Bit OFF (0) = Non-idle
11
(2)
(2)
Bit 0 corresponds to Node 16, Bit 1 corresponds to Node 17 … Bit 15 corresponds to Node 31.
Node 16…31
12
(3)
(3)
Bit 0 corresponds to Node 32, Bit 1 corresponds to Node 33 … Bit 15 corresponds to Node 47.
Node 32…47
13
(4)
(4)
Bit 0 corresponds to Node 48, Bit 1 corresponds to Node 49 … Bit 15 corresponds to Node 63.
Node 48…63
