92

Publication 1769-UM009E-EN-P - August 2009

Chapter 6 DeviceNet I/O Image

Reserved Array

Device Status Array

The Device Status Array is a 64-byte array containing the information shown
in this table. Each byte indicates the status code of the scanner’s master and
the slave devices.

Reserved Array

Input Word

Description

(1)

(1)

Do not manipulate reserved bits. Doing so may interfere with future compatibility.

2231

Always 0

Device Status

Input Word

Bit

Description

32

0…7 (lower byte)

Node 0 DeviceNet status

8…15 (upper byte)

Node 1 DeviceNet status

33

0…7 (lower byte)

Node 2 DeviceNet status

8…15 (upper byte)

Node 3 DeviceNet status

...

...

...

63

0…7 (lower byte)

Node 62 DeviceNet status

8…15 (upper byte)

Node 63 DeviceNet status
