Publication 1769-UM009E-EN-P - August 2009

101

DeviceNet I/O Image Chapter 6

Fault

This bit forces the scanner into a faulted condition.

• 0 = Network is not faulted
• 1 = Network is faulted

Disable Network

This bit disables the DeviceNet network.

• 0 = Network is not disabled
• 1 = Network is disabled

Halt Scanner

This bit halts the scanner.

• 0 = Scanner is not halted
• 1 = Scanner is halted

Reset

This bit resets the scanner.

• 0 = The scanner has not been reset
• 1 = The scanner has been reset.

Do not leave this bit = 1. If you do not change the bit back to 0, the scanner
continuously resets.
