Publication 1760-UM001D-EN-P - September 2005
Commission the Pico 3-9
3. Press Esc to return to the Main Menu. A circuit diagram does not
have to be completed before you can test parts of it with Pico.
Pico simply ignores any incomplete wiring that is not yet
working and only uses the finished wiring.
Delete a Circuit Diagram
1. Switch Pico to Stop mode.
The RUN option is displayed. Pico must be in Stop mode in
order to extend, delete or modify the program.
2. Select ’PROGRAM’. Press Ok to switch from the main menu to
the next menu level.
3. Select ’DELETE PROG’
Pico displays the prompt ’DELETE?’.
4. Press Ok to delete the program or Esc to cancel.
5. Press Esc to return to the Main Menu.
Fast Circuit Diagram Entry
You can create a circuit diagram in several ways. The first option is to
enter the elements in the circuit diagram and then wire all the
elements together. The other option is to use the enhanced operator
guidance and create the circuit diagram, from the first contact through
to the last coil.
If you use the first option, you have to select some of the elements in
order to create and connect your circuit diagram.
The second, faster option is what you learned in the example. In this
case you create the entire circuit connection from left to right.
PROGRAM
DELETE PROG
