Draw a Circuit Diagram with Pico 4-41
Parameter Display and Parameter Set for the High-Speed Counter
In the parameter display of a counter relay you change the mode, the
setpoint and the enable of the parameter display.
Value Range
The counter relay is in Run mode.
Behavior When Value Range is Reached
The Pico control relay is in Run mode.
The value is retained if the counter reaches 32000. If the counter
counts down and reaches 0, this value is retained.
Parameter display in Run mode:
Retention
The high-speed counter can be run with the retentive actual value.
You can select the retentive counter relays in the System menu by
selecting Retention. C5 to C7, C8 and C13 to C16 can be selected.
If a counter relay is retentive, the actual value is retained when the
operating mode changes from Run to Stop as well as when the power
supply is switched off.
C13 Counter function relay number 13.
H H - High-speed counter mode.
+
• + appears in the Parameter menu.
• - does not appear in the Parameter
menu.
S Setpoint, constant from 00000 to 32000.
C13 H +
00950 S
C13 H +
00200
C:00877
S
Current setpoint, constant
Contact has not switched.
Contact has switched. Actual value (0153)
