Publication 1760-UM001D-EN-P - September 2005
5-4 Save and Load Circuit Diagrams
Store a Circuit Diagram to the Memory Module
1. Select DEVICE-> CARD.
2. Confirm the prompt by pressing Ok. This
deletes the contents of the memory module
and replaces it with the program in Pico.
3. Press Esc to cancel.
Load a Circuit Diagram from the Memory Module
1. Select the CARD-> DEVICE menu option.
2. Press Ok if you want to delete the Pico
program and replace it with the memory
module program.
3. Press Esc to cancel.
If a problem occurs during the operation, Pico
displays the message “INVALID PROG”.
This either means that the memory module is
empty or that the program in the memory module
contains functions that Pico does not recognize.
• The time switch function relays only work with Pico versions
with a real-time clock.
• The analog comparator function is only used with 12V dc and
24V dc versions of Pico.
• Text displays, jump and ’S’ markers only work with the
1760-L18xxx.
Delete a Program from the Memory Module
1. Select the DELETE CARD menu option.
2. Press Ok to confirm the prompt and delete
the card content.
3. Press Esc to cancel.
IMPORTANT
If the memory module is password-protected, the
password will also be transferred to the Pico memory
and will be active immediately
REPLACE ?
>
>
DEVICE - CARD
CARD - DEVICE
DELETE CARD
INVALID PROG
DELETE ?
