Cycle Time 1760-L12xxx
1760-L18xxx
Function Number Time Duration
in µs Total
Basic pulse 1 210
Refresh 1 3500
Contacts and bridged contact fields 20
Coils 20
Circuit connections from the first one to the
last one, with empty ones in between 0
Connecting lines, only 20
Timing relays (see Table below)
Counters (see Table below)
Analog value function relays (see Table
below)
Total
Number 1 2 3 4 5 6 7 8
Timing relays in µs 20 40 80 120 160 200 240 280
Counters in µs 20 50 90 130 170 210 260 310
Analog value processors in µs 80 100 120 140 160 180 220 260
Function Number Time Duration (µs) Total
Basic pulse 1 520
Refresh 5700
Contacts and bridged contact fields 40
Coils 20
Circuit connections from the first one to the
last one, with empty ones in between 70
Connecting lines, only 40
Timing relays (see Table below)
Counters (see Table below)
Analog value function relays (see Table
below)
Total
, ,
, ,
