3 - commission the pico, Power on unit, Chapter 3 – Rockwell Automation 1760-xxxx Pico Controller User Manual User Manual
Page 51: Commission the pico, Power on unit -1, Chapter
1
Publication 1760-UM001D-EN-P - September 2005
Chapter
3
Commission the Pico
Power On Unit
Before powering up Pico, check that you have connected the power
supply terminals and inputs correctly.
12V dc version:
• +12V terminal: +12V dc voltage
• COM terminal: 0V voltage
• terminals I1 to I8: actuation via +12V dc
24V dc version:
• +24V terminal: +24V dc voltage
• COM terminal: 0V voltage
• terminals I1 to I12, R1 to R12: actuation via +24V dc
100 to 240V ac version:
• terminal L1: phase conductor L1
• terminal L2: neutral conductor L2 (grounded)
• terminals I1 to I12, R1 to R12: actuation via phase conductor L1
ATTENTION
If you have already installed Pico into a system,
ensure that the working area of all connected
devices is secure. Advise all personnel of start-up to
avoid injury in the event of unexpected operation.
