Chapter
3
Installing the 1203-GK5 Module or
1336-GM5 Board
Chapter Objectives
Chapter 3 provides the information that you need to install the
1203-GK5 module or 1336-GM5 board. In this chapter, you will read
about the following:
•
Selecting cables for the SCANport and DeviceNet connections.
•
Installing and removing either the 1203-GK5 module or the
1336-GM5 board.
Read “Selecting Cables” on page 3-1. Then, refer to either“Installing
a 1203-GK5 Module” on page 3-3 or “Installing a 1336-GM5 Board”
on page 3-7.
Selecting Cables
Refer to the following table to determine the cables that you need:
Use the following information to select appropriate cables for each
required connection.
SCANport Cables
When selecting the SCANport cable to connect the 1203-GK5
module to the SCANport product, you need to:
•
Use an Allen-Bradley SCANport cable. Refer to the table below.
•
Use less than 10 meters (33 feet) of cable between the SCANport
product and adapter.
•
Keep SCANport cables away from high power cables to guard
against introducing noise into your system.
If installing:
Required Cables
1203-GK5 module
SCANport and DeviceNet
1336-GM5 board
DeviceNet
Male to Male Connection
Male to Female Connection
Length
Catalog Number
Length
Catalog Number
1/3 m
1202-C03
1/3 m
1202-H03
1 m
1202-C10
1 m
1202-H10
3 m
1202-C30
3 m
1202-H30
9 m
1202-C90
9 m
1202-H90
