DeviceNet Objects (Class Code 0x99 — SCANport Pass-Through Link Object)

C-25

Class Code 0x99 — SCANport
Pass-Through Link Object

The SCANport Pass-Through Link Object lets you perform a
scattered read or write of a number of links or a single read or write of
a link.

Class Attributes

Instance Attributes

Common Services

Object-Specific Services

Attribute ID

Access Rule

Name

Data Type

Description

0

Set

Link Command

BYTE

1 = Clear all links.

1

Get

NVS Link Diagnostic Value

WORD

Checksum.

Attribute ID

Access Rule

Name

Data Type

Description

0

Set

Parameter Link Reference

WORD

Important: An instance in this class is the number of a parameter that is to get its value from another parameter.

The Parameter Link Reference value is the number of the parameter whose value is to be transferred.

Service Code

Implemented for:

Service Name

Class

Instance

0x0E

Yes

Yes

Get_Attribute_Single

0x01

Yes

Yes

Set_Attribute_Single

Service Code

Implemented for:

Service Name

Class

Instance

0x32

Yes

No

Scattered_Link_
Reference_Value_Read

0x34

Yes

No

Scattered_Link_
Reference_Value_Write

Must be directed to Attribute 0, Instance 0.
