Appendix
E
N-File Addresses
Appendix Objectives
Appendix E provides information on the N-File addresses used when
accessing the PCCC object. When using messages, you can use the
N-file addresses to locate information about the adapter or SCANport
product.
N-File Addresses
The 1203-GK5 and 1336-GM5 support the N-file addresses shown
below:
Address
N-File Addresses
N10:0
Number of SCANport product parameters
N10:1 – 999
SCANport product parameters 1 – 999 (value only)
N11:0 – 999
SCANport product parameters 1000 – 1999 (value only)
N12:0 – 999
SCANport product parameters 2000 – 2999 (value only)
N13:0
Number of SCANport adapter parameters
N13:1 – 999
SCANport adapter parameters 1 – 999 (value only)
N30:1 – 999
SCANport product parameters 1 – 999 (all information — read only)
N31:1 – 999
SCANport product parameters 1000 – 1999 (all information — read
only)
N32:1 – 999
SCANport product parameters 2000 – 2999 (all information — read
only)
N33:1 – 999
SCANport adapter parameters 1 – 999 (all information — read only)
N40:0 – 63
Block Transfer Emulation file
N42:5
1203-GK5 Firmware Emulation Version — The firmware version of the
1203-GK5 this adapter emulates for DriveTools compatibility.
N42:6
Max Network Node — The maximum DeviceNet Node Number
N42:7
Adapter Port # — The SCANport adapter port number the adapter is
connected to on the SCANport product
N42:8
Reserved for future use — Always zero
