P-2 Using this Manual
Contents of this Manual
This manual contains the following information:
Related Publications
Chapter Title Contents
Preface Using this Manual Describes the purpose, background, and scope of this manual. Also provides information on
safety precautions and technical support.
1 Overview Provides an overview of the 1203-GK5 module, 1336-GM5 board, DeviceNet, and SCANport™.
2 Configuring the 1203-GK5 Module
or 1336-GM5 Board Provides procedures for configuring the 1203-GK5 module and 1336-GM5 board using the DIP
switches.
3 Installing the 1203-GK5 Module or
1336-GM5 Board Provides procedures for installing the 1203-GK5 module or 1336-GM5 board.
4 Configuring a Scanner to
Communicate with the 1203-GK5
Module or 1336-GM5 Board Provides procedures for using DeviceNet Manager to configure scanners to communicate with
devices connected to the network with a 1203-GK5 module or 1336-GM5 board.
5 Creating a Ladder Logic Program Provides an example ladder logic program for a PLC
®
and an example ladder logic program for
an SLC
®
.
6 Using DeviceNet Explicit Messages Provides information about explicit messaging, including messaging with PLCs, messaging with
SLCs, and using messages to control the SCANport product.
7 Troubleshooting Provides information on how to troubleshoot the 1203-GK5 module or 1336-GM5 board using
the LEDs.
A Specifications Provides the specifications for the 1203-GK5 module and 1336-GM5 board.
B Parameters in the 1203-GK5
Module and 1336-GM5 Board Describes the parameters in the 1203-GK5 module and 1336-GM5 board.
C DeviceNet Objects Defines the DeviceNet object classes, class services, and attributes that are supported by the
1203-GK5 module and the 1336-GM5 board.
D Supported PCCC Messages Provides a reference list of PCCC messages supported by the 1203-GK5 module and
1336-GM5 board.
E N-File Addresses Lists the N-files to which messages can be written.
F Supported Emulated Block Transfer
Commands Provides a reference list of emulated block transfer commands.
Title Publication Number
DeviceNet Manager Software User Manual 1787-6.5.3
1771-SDN Scanner Configuration Manual 1771-6.5.118
DeviceNet Scanner Configuration Manual 1747-6.5.2
DeviceNet Cable System Planning and Installation Manual DN-6.7.2
