C-14
DeviceNet Objects (Class Code 0x0F — Parameter Object)
Get_Attribute_All Response
Not supported.
At the instance level, the order of attributes returned in the
Get_Attributes_All response is as follows:
Object Specific Services
Enumerated strings are human-readable strings that describe either a
bit or a value depending on the data type of instance attribute 1, the
Parameter Value. If the data type is a BYTE or WORD, the
enumerated string is a bit enumerated string. If the data type is INT or
UINT, the enumerated string is a value enumerated string. Any other
data type does not have enumerated strings.
Class Attribute ID
Attribute Name and Default Value
1
Parameter Value
2
Link Path Size
3
Link Path
4
Descriptor
5
Data Type
6
Data Size
7
Parameter Name String, default character count = 0
8
Units String, default character count = 0
9
Help String, default character count = 0
10
Minimum Value default = 0
11
Maximum Value default = 0
12
Default Value default = 0
13
Scaling Multiplier Default = 1
14
Scaling Divisor Default = 1
15
Scaling Base Default = 1
16
Scaling Offset Default = 0
17
Multiplier Link Default = 0
18
Divisor Link Default = 0
19
Base Link Default = 0
20
Offset Link Default = 0
21
Decimal Precision Default = 0
Service Code
Implemented for:
Service Name
Class
Instance
0x4B
No
Yes
Get_Enum_String
