Publication 0160-5.5 - September 1997
DeviceNet Information B-17
Class Code 0xB4 —
DN Interface Object
Instance 1 Attributes:
➀ If set to a “9” P9 - [Drive Status] (of the SSC Interface Profile) goes in the low byte of the assembly field and P12 - [Input Status] (of the SSC Interface
Profile) goes in the high byte of assembly field.
Common Services
Class Attributes: None Supported Number of Instances: 1
Attribute ID
Access
Rule
Name
Data
Type
Min/Max Default Description
1 Get Zero USINT 0 0 Returns zero.
2 Get/Set Interface Select USINT 0 to 1 0
0 = Bulletin 160 SSC Interface.
1 = ODVA Drive Profile Interface.
3 Get
MAC ID
Switches
USINT 0 to 63 Reflects the state of the MAC ID switches.
4 Get Baud Switches USINT 0 to 3 Reflects the state of the Baud Rate switches.
5 Get/Set
Nonvolatile MAC
ID
USINT 0 to 63 63
Stored value of the MAC ID. This value is used when Baud
Switches = 3.
6 Get/Set Nonvolatile Baud USINT 0 to 2 0
Stored value of Baud Rate. This value is used when Baud
Switches = 3.
7 ➀ Get/Set
Assembly
Word 0 Param
USINT
0 to 88 (0 to 9
for version 1.2)
9
Bulletin 160 SSC Interface parameter number whose value is
used as the first word in Input Assembly 102.
8 ➀ Get/Set
Assembly
Word 1 Param
USINT
0 to 88 (0 to 9
for version 1.2)
0
Bulletin 160 SSC Interface parameter number whose value is
used as the second word in Input Assembly 102.
9 ➀ Get/Set
Assembly
Word 2 Param
USINT
0 to 88 (0 to 9
for version 1.2)
0
Bulletin 160 SSC Interface parameter number whose value is
used as the third word in Input Assembly 102.
10 ➀ Get/Set
Assembly
Word 3 Param
USINT
0 to 88 (0 to 9
for version 1.2)
0
Bulletin 160 SSC Interface parameter number whose value is
used as the fourth word in Input Assembly 102.
11 Get/Set DN Idle Mode Boolean 0 to 1 0 0 = Stop, 1 = Hold Last State. (Version 2.00 and later.)
12 Get
DN Software
Version
Word 0.00 to 10.00 2.00
Indicates the software version of the DeviceNet option. (Ver-
sion 2.00 and later.)
13 Get/Set
DN Change of
State Mask
Word 0 to 0xFFFF 0xFFFF
A 16 bit mask used to enable automatic change of state mes-
sages. (Version 2.00 and later.)
14 Get/Set
Local Return
Mode
Byte 0 to 5 0
Sets the input mode the drive will use when transitioning from
network to local control. (version 2.00 and later.)
Service
Code
Implemented for:
Service
Name
Class Instance
0x0E No Yes Get_Attribute_Single
0x10 No Yes Set_Attribute_Single
