Rockwell Automation 160 DEVICENET (DN1) MODULE FRN 1-2.XX User Manual
Page 101
Publication 0160-5.5 - September 1997
C-10
ODVA Interface Parameter Descriptions
ODVA Drive Profile Interface
Parameters (Continued)
Parameter
Number
Parameter
Group
Name and Description
Object
Mapping
(Class-
Instance-
Attribute)
Min./Max.
Range
Units
Factory
Default
63
Preset
[DN Preset Cmd]
This read/write parameter acts as the network preset command.
0x2A-1-192 0 to 7
Numeric
Value
0
64
Preset
[Preset RPM 0]
This read/write parameter sets the speed that the drive outputs when
selected.
0x2A-1-161 0 to 32000
1 RPM
90 RPM
65
Preset
[Preset RPM 1]
This read/write parameter sets the speed that the drive outputs when
selected.
0x2A-1-162 0 to 32000
1 RPM
600 RPM
66
Preset
[Preset RPM 2]
This read/write parameter sets the speed that the drive outputs when
selected.
0x2A-1-163 0 to 32000
1 RPM
900 RPM
67
Preset
[Preset RPM 3]
This read/write parameter sets the speed that the drive outputs when
selected.
0x2A-1-
164
0 to 32000
1 RPM
1200 RPM
68
Preset
[Preset RPM 4]
This read/write parameter sets the speed that the drive outputs when
selected.
0x2A-1-
165
0 to 32000
1 RPM
1350 RPM
69
Preset
[Preset RPM 5]
This read/write parameter sets the speed that the drive outputs when
selected.
0x2A-1-
166
0 to 32000
1 RPM
1500 RPM
70
Preset
[Preset RPM 6]
This read/write parameter sets the speed that the drive outputs when
selected.
0x2A-1-
167
0 to 32000
1 RPM
1650 RPM
71
Preset
[Preset RPM 7]
This read/write parameter sets the speed that the drive outputs when
selected.
0x2A-1-
168
0 to 32000
1 RPM
1800 RPM
72
Preset
[Accel Time 2]
This read/write parameter sets the acceleration time for parameters 68 to
71 (preset RPM 4-7).
0x2A-1-
169
100 to
65500
1ms
20000 ms
72
AC Drive
Extension
[Accel Time 2]
This read/write parameter sets the acceleration time.
0xB3-1-69
0-60000
1 ms
20000 ms
73
Preset
[Decel Time 2]
This read/write parameter sets the deceleration time for parameters 68 to
71 (preset RPM 4-7).
0x2A-1-
170
100 to
65500
1ms
20000 ms
73
AC Drive
Extension
[Decel Time 2]
This read/write parameter sets the deceleration time.
0xB3-1-70
10 to 60000 1 ms
20000 ms
This parameter applies only to the Analog Signal Follower model.
This parameter applies only to the Preset Speed model.
