Publication 0160-5.5 - September 1997
B-8 DeviceNet Information
Class Code 0x05 —
Connection Object (Continued)
Instance 4 Attributes: Change of State/Cyclic Instance
(Available with Communication Module version 2.00 and later)
Common Services
Attribute ID Access Rule Name Data Type Value
1 Get State USINT
0 = Nonexistant
1 = Configuring
3 = Established
4 = Timed out
2 Get Instance Type USINT 1 = I/O Message
3 Get Transport Class Trigger USINT 0x82
4 Get Produced Connection ID USINT 10xxxxxx100 xxxxxx = Node address
5 Get Consumed Connection ID USINT 10xxxxxx101 xxxxxx = Node address
6 Get Initial Comm Characteristics USINT 0x21
7 Get Produced Connection Size USINT 0 to 8
8 Get Consumed Connection Size USINT 0 to 4
9 Get/Set Expected Packet Rate UINT timer resolution of 10 msec.
12 Get/Set Watchdog Action USINT
0 = transition to timed out
1 = auto delete
2 = auto reset
13 Get Produced Connection Path Length USINT 3
14 Get/Set Produced Connection Path
[63hex][hex string] where [hex string] is the
input assembly number in hex
15 Get Consumed Connection Path Length USINT 3
16 Get/Set Consumed Connection Path
[63hex][hex string] where [hex string] is the
output assembly number in hex
17 Get/Set Production Inhibit Time UINT 0
Service
Code
Implemented for:
Service
Name
Class Instance
0x05 No Yes Reset
0x0E Yes Yes Get_Attribute_Single
0x10 No Yes Set_Attribute_Single
