Publication 0160-5.5 - September 1997
DeviceNet Parameter Descriptions 5-9
Drive Program Parameters Below is a brief description of the Bulletin 160 SSC Interface Pro-
gram Group parameters. Refer to the Bulletin 160 SSC User Manual
for more detailed information on these parameters.
Parameter
Number
Parameter Name
Object Mapping
(Class-Instance-
Attribute)
Description Units
30 [Accel Time 1] 0xB3-1-30 Time to ramp from 0 Hz to maximum frequency. 0.1 Seconds
31 [Decel Time 1] 0xB3-1-31 Time to ramp from maximum frequency to 0 Hz. 0.1 Seconds
32 [Minimum Frequency] 0xB3-1-32 Lowest continuous output frequency. 1 Hz
33 [Maximum Frequency] 0xB3-1-33 Highest continuous output frequency. 1 Hz
34 [Stop Mode Select] 0xB3-1-34 Determines stop mode used. Numeric Value
35 [Base Frequency] 0xB3-1-35 Set to motor’s nameplate frequency. 1 Hz
36 [Base Voltage] 0xB3-1-36 Set to motor’s nameplate voltage. 1 Volt
37 [Max Voltage] 0xB3-1-37 Highest voltage the drive will output. 1 Volt
38 [Boost Select] 0xB3-1-38 Sets the volts/Hz relationship. Numeric Value
39 [Skip Frequency] 0xB3-1-39 Frequency at which drive will not run continuously. 1 Hz
40 [Skip Frequency Band] 0xB3-1-40 Used with P39 - [Skip Frequency] to create skip band. 1 Hz
41 [Overload Select] 0xB3-1-41 Selects derating factor for motor overload. Numeric Value
42 [Overload Current] 0xB3-1-42 Set to motor nameplate full load amperes. 0.01 Amperes
43 [Current Limit] 0xB3-1-43 Max output current allowed before limiting. % I rating
44 [DC Hold Time] 0xB3-1-44 DC Injection Braking duration. 0.1 Seconds
45 [DC Hold Voltage] 0xB3-1-45 Voltage level for DC Injection Braking. 1 Volt
46 [Input Mode] 0xB3-1-46 Type of START, STOP, REV, commands. Numeric Value
47 [Output Configure] 0xB3-1-47 Configures TB3 output relay functionality. Numeric Value
48 [Output Threshold] 0xB3-1-48 Used in conjunction with P47 - [Output Configure]. Numeric Value
49 [PWM Frequency] 0xB3-1-49 Carrier frequency for PWM output waveform. 0.1 kHz
50 [Restart Tries] 0xB3-1-50 Times drive will attempt to reset a fault. Numeric Value
51 [Restart Time] 0xB3-1-51 Time between restart attempts. 0.1 Seconds
52 [DB Enable] 0xB3-1-52 Enables/disables dynamic braking. Numeric Value
53 [S-Curve] 0xB3-1-53 Enables a fixed shape S-curve. Numeric Value
!
ATTENTION: Changing this parameter
value may cause unpredictable network
conditions, resulting in equipment damage,
personal injury, or death. Ensure that you
understand how changing this parameter
affects your application.
!
ATTENTION: Changing this parameter
value may cause unpredictable network
conditions, resulting in equipment damage,
personal injury, or death. Ensure that you
understand how changing this parameter
affects your application.
