52
REPLACEMENT PARTS TABLE
Symbol
(in wiring
diagram)
Part Name Code No. Specifications manufacturer
CT1 Current detector 2170010002 CLT-6-P-400 URD
MCB Circuit Breaker A0194 BS2021 15A Matsushita
H1,H2 Heater HC200H AC100V 56W Yamato Scientific
PIO Display circuit board 1240000028 Model HITECH-IV
FR
PIO-2 Yamato Scientific
PLANAR Control circuit board 1240000035 Model HITECH-IV
FR
Yamato Scientific
FAN Cooling fan HC200FAN MU123BA-11B Yamato Scientific
SSR Solid-state relay 2160000010 SSR-01 Yamato Scientific
TR1 Transformer 1013200005 for HITECH-IV
FR
, 100V Yamato Scientific
TE1 Thermistor 1160050010 Yamato Scientific
X1,X2,X3 Relay 2050000013 JR1aF-TM-DC6V Matsushita
C1,C2 Peltier cells HC200CU Yamato Scientific
CC
Circuit board for
peltier
HC200CC Yamato Scientific
