Wasp Labeler User Manual
POSTNET Properties Box Options
The table below lists the options available for POSTNET in the Properties box > Barcode tab.
Field
Description
Symbology
Select POSTNET from the drop down list. For a complete list of
available symbologies along with examples and descriptions of each,
please refer to the topic
Short Bar
Height
This setting determines how tall the short bars on your barcode will
be. The bar height does not affect density.
Tall Bar
Height
This setting determines how tall the tall bars on your barcode will be.
The bar height does not affect density.
Bar Width
This setting determines density of the barcode. Increase the bar
width (applies to the individual bars in the barcode) and the density is
decreased. You might want a more dense barcode to fit on a small
label, for example. Keep in mind that a barcode that is too dense
may be harder for a scanner to read and may not be scannable at all.
Columns
Select the number of columns for your barcode (1-30).
Ratio
This is the wide to narrow bar ratio. The default setting is (1:1).
