Wasp Labeler User Manual
MicroQRCode Properties Box Options
The table below lists the options available for MicroQRCode in the Properties box > Barcode tab.
Field
Description
Symbology
Select MicroQRCode from the drop down list. For a complete list of
available symbologies along with examples and descriptions of each,
please refer to the topic
Code Version
Select the Code Version for your barcode. You have five options:
• Auto - Use this option to have Labeler select the version for
you based on the barcode's content.
• M1 - This version is capable of encoding:
o
up to 5 numeric characters with no error correction.
• M2 - This version is capable of encoding:
o
up to 10 numeric characters and 6 alphanumeric
characters with L error correction or,
o
up to 8 numeric characters and 5 alphanumeric
characters with M error correction.
• M3 - This version is capable of encoding:
o
up to 23 numeric characters and 14 alphanumeric
characters with L error correction or,
o
18 numeric characters and 11 alphanumeric
characters with M error correction.
• M4 - This version is capable of encoding:
o
up to 35 numeric characters and 21 alphanumeric
characters with L error correction,
o
up to 30 numeric characters and 18 alphanumeric
characters with M error correction or,
o
up to 21 numeric characters and 13 alphanumeric
characters with Q error correction level.
Error
Correction
Level
Select the Error Correction Level. Options are:
• L - Approx 7% capability
• M - Approx 15% capability
• Q - Approx 25% capability
• H - Approx 30% capability
Code
Encoding
Select the type of data you want to encode. Options are:
• AlphaNumeric
• Auto
• Byte
• Numeric
Code Module
Size
Select the size ofyour barcode or let Labeler determine the sized
based on content or previous selections.
