85
Wasp Labeler User Manual
EAN/JAN 8 Properties Box Options
The table below lists the options available for EAN/JAN 8 in the Properties box > Barcode tab.
EAN/JAN 8
Field Description
Symbology
Select EAN/JAN 8 from the drop down list. For a complete list of
available symbologies along with examples and descriptions of each,
please refer to the topic
Barcode Symbology Reference .
% of Nominal
The nominal size for a EAN/JAN barcode is 1inch. The usual
reduced size is 80% of the nominal size.
Specify Bar
Height
Check this box to enter a specific bar height.
Bar Height Enter the exact bar height in the field provided.
EAN/JAN 13 Properties Box Options
The table below lists the options available for EAN/JAN 13 in the Properties box > Barcode tab.
EAN/JAN 13
Field Description
Symbology
Select EAN/JAN 13 from the drop down list. For a complete list of
available symbologies along with examples and descriptions of each,
please refer to the topic
Barcode Symbology Reference .
% of Nominal
The nominal size for a EAN/JAN barcode is 1inch. The usual
reduced size is 80% of the nominal size.
Specify Bar
Height
Check this box to enter a specific bar height.
Bar Height Enter the exact bar height in the field provided.
