Page 269: Appendix a technical specifications

Product Reference Guide
259
Appendix A
Technical Specifications
contains Physical and Performance Characteristics, User Environment and Regulatory
information. Table
provides Standard Cable Pinouts.
Table 45. Technical Specifications
Item
Description
Physical Characteristics
Color
Black/Yellow
Dimensions
Height 7.1”/181 mm
Length 3.9”/100 mm
Width 2.8”/71 mm
Weight (without cable)
Approximately 6.0 ounces/169 g
Electrical Characteristics
Voltage & Current
Input current at 5V±5% = 260 mA (max)
2.5 mA (USB suspend)
Standby (typical) <= 30mA
Performance Characteristics
Light Source
650nm Class 2 Laser
Roll (Tilt) Tolerance
± 35° from normal
Pitch Tolerance
± 50°
Skew (Yaw) Tolerance
± 65°
Field of View
Scan Angle: 47° (normal) or 35° (narrow)
Depth of Field (Typical)
a
(
5 mil - 1.4" to 6.22" (3,6cm to 15,8cm)
13 mil
a
– 0.87" to 18.7" (2,2cm to 47,5cm)
20 mil – up to 27.1" (to 69cm)
Minimum Element Width
4 mil
Print Contrast Minimum
15% minimum reflectance
