TCI HGA Manual User Manual
Page 25
25
Table 3.4 – UL Type 3R Enclosed
Amps
HeatLoss
(watts)
Weight lbs.
(kg)
Dimensions Inch (cm)
H x W x D
39
Consult Factory
50
3176
371 (168.3)
80.00 (203.2)
32.00 (81.3)
25.00 (63.5)
78
Consult Factory
100
3500
371 (168.3)
80.00 (203.2)
32.00 (81.3)
25.00 (63.5)
200
7000
1040 (472)
80.00 (203.2) 57.00 (144.78) 25.00 (63.5)
300
Consult Factory
Table 3.5 – Transformer for 600V units – Open and Type 3R
Amps
Encl.
Heat Loss
(watts)
Weight
lbs. (kg)
Dimensions Inch (cm)
H x W x D
39
Open
345
180 (81.7)
16.00 (40.7)
19.50 (49.6)
12.20 (31)
78
Open
740
180 (81.7)
16.00 (40.7)
19.50 (49.6)
12.20 (31)
39
3R
345
270 (122.5)
24.90 (63.3)
24.40 (62)
20.80 (52.9)
78
3R
740
270 (122.5)
24.90 (63.3)
24.40 (62)
20.80 (52.9)
