TCI V1k - Manual

V1k
Installation
Guide
TCI, LLC
W132 N10611 Grant Drive
Germantown, Wisconsin 53022
Ph: 800-TCI-8282
www.transcoil.com
Version 3.8 Part # 25316 March 21, 2014
TCI, LLC
W132 N10611 Grant Drive
Germantown, Wisconsin 53022
Ph: 800-TCI-8282
www.transcoil.com
Field Wiring
Field Wiring Connection Terminals
Compression type terminals are provided for all line
wiring connections. The wire size capacity ranges and
tightening torque for the power terminals are listed in the
table.
Warnings and Cautions
Dangerous Voltage Warning: warns of
situations in which a high voltage can
cause injury and/or equipment damage.
The text next to this symbol describes
ways to avoid danger.
General Warning: warns of situations
that can cause physical injury and/
or equipment damage by means other
than electrical. The text next to this
symbol describes ways to avoid the
danger.
General Safety Instructions
Be sure to read, understand, and follow
all safety instructions.
Only qualified electricians should
carry out all electrical installation and
maintenance work on V1k drive output
filters.
All wiring must be in accordance with
the National Electrical Code (NEC)
and/or any other codes that apply to
the installation site.
Disconnect all power before working
on the equipment. Do not attempt any
work on a powered V1k output filter.
The V1k, VFD, motor, and other
connected equipment must be properly
grounded.
The VFD terminals and connected
cables are at a dangerously high voltage
when power is applied to the VFD,
regardless of motor operation.
Warning
Warning
Warning
Warning
Warning
Warning
Warning
Warning
!
!
!
!
See www.transcoil.com for dimensions tables. Please contact
TCI Technical Support or your TCI distributor for application
information regarding the use of V1k output filters on the
output side of the VFD.
V1k Model
Numbers
Input and Output Motor Power
Wire Size
Torque
(in.-lb.)
V1k2A to V1k12A 12 - 14 10
V1k16A 4 - 12 20
V1k18A to V1k21A 4 - 10 20
V1k25A to V1k27A 4 - 8 20
V1k35A 6 - 8 30
V1k45A 6 30
V1k55A 1 - 4 35
V1k80A 1 - 3 35
V1k110A 2/0 - 1/0 50
V1k130A 2/0 50
V1k160A 250 MCM - 3/0 375
V1k200A two 2/0 - 1 50
V1k250A two 2/0 50
V1k305A
600 MCM,
two 500 MCM - 3/0
500
V1k362A two 350 MCM - 4/0 375
V1k420A two 600 MCM - 300 500
V1k480A two 600 MCM - 350 500
V1k600A two 600 MCM - 500 MCM 500
V1k750A three 600 MCM - 400 MCM 500
All electrical connections must be
re-torqued annually.
