8.1.6
CA25 Feed Auger Flighting
Flighting extensions are available as an option for the CA25
feed auger.
The flighting extension kit may improve feeding in certain
crops such as rice or heavy green crop. They are not
recommended in cereal crops.
MD #B4829
Figure 8.6
8.1.7
Knifehead Shield
The shields attach to the endsheets and reduce the
knifehead opening to prevent cut crop, particularly severely
lodged crop, from accumulating over the knifehead, which
could damage the knife drive box and the endsheet.
Order kit according to header size and guard type.
Regular Guards :
• 30 ft. and larger – MD #220101
Stub Guards :
• 30 ft. and larger – MD #220103
Figure 8.7
8.1.8
Lodged Crop Reel Finger Kit
The steel fingers attach to ends of every other tine bar and
help in clearing material in heavy, hard-to-cut crops such
as lodged rice.
Two kits are required for modifying each bar of a 6-bat reel.
Installation and adjustment instructions are included with
the kit.
MD #B4831
Figure 8.8: Steel Fingers`
169894
417
Revision A
