5
Header Attachment/Detachment
This chapter includes instructions on setting up, attaching, and detaching the header.
Combine
Section
Case IH 7010, 8010, 7120, 8120, 9120, 5088, 6088,
7088, 5130, 6130, 7130, 7230, 8230, 9230
5.2 Case IH Combines, page 191
John Deere 60, 70, and S Series
5.3 John Deere Combines, page 198
Lexion 500, 700 (R Series)
New Holland CR, CX
5.5 New Holland Combines, page 213
AGCO Gleaner R and S Series, Challenger 660, 670,
680B, 540C, 560C, Massey 9690, 9790, 9895, 9520,
9540, 9560
NOTE:
Ensure applicable functions (Automatic Header Height Control (AHHC), Draper Header Option, Hydraulic
Center-Link Option, Hydraulic Reel Drive etc.) are enabled on the combine and in the combine computer.
Failure to do so may result in improper header operation.
5.1
Adapter Setup
The following sections outline recommended adapter setup guidelines, depending on your combine and crop. The
recommendations cannot cover all conditions.
If feeding problems develop with adapter operation, Refer to
5.1.1
Using Flighting Extensions
The flighting extension kit may improve feeding in certain crops such as rice or heavy green crop, but they are not
recommended in cereal crops.
Refer to
8.1.6 CA25 Feed Auger Flighting, page 417
for more information.
For servicing information, refer to:
•
Installing Flighting Extensions, page 298
•
Removing Flighting Extensions, page 299
5.1.2
Using Stripper Bars
Stripper bar kits may have been supplied with your header to improve feeding in certain crops such as rice. They
are NOT recommended in cereal crops.
For servicing information, refer to
6.10 Adapter Stripper Bars and Feed Deflectors, page 332
169894
189
Revision A
