Lenze 931E/K Small Drives Control - Manual (Page 177)

Appendix
Timing charts
Switch−on sequence
10
l
177 SW−HB 13.0002−EN 4.1
10.5.1 Switch−on sequence
t
1
t
2
t
3
t
4
t
5
t
6
t
7
t
t
t
t
t
t
t
931E_121
Fig. 31 Switch−on sequence
0 Power on
1 DOUT0: Ready
2 Controller enable
3 Power stage is on
4 Holding brake released
5 Speed setpoint
6 Actual speed
