User interface
Building up serial communication
4
l
13 SW−HB 13.0002−EN 4.1
ƒ Retry with old parameters (COM3, 9600 Baud):
To solve the access conflict with a program using the interface, close the other program
(with MS−DOS programs, also close the MS−DOS shell!!) and click Retry with old parameters
(COM3, 9600 Baud).
ƒ Change COM port:
Click Change COM port to correct a wrong interface setting and select a different interface.
ƒ Search Baud rates:
Under certain conditions, the servo positioning controller may use a baud rate other than
the baud rate selected in the parameterisation program. If you select Search Baud rates,
the parameterisation program will try to build up communication with different baud
rates.
ƒ Offline parameterisation:
The Offline parameterisation is only useful, if you want to edit parameter set files without
the servo positioning controller. For more information, please see the chapter "Offline
parameterisation". (
¶ 186)
ƒ Firmware download:
If the servo positioning controller contains an invalid firmware version or if you want to
download a new firmware, select Firmware download to initiate the firmware download.
ƒ Exit program:
Click Exit program to exit the program.
The below table lists possible error causes and troubleshooting strategies:
Error Remedy
Communication problem Click Retry with old parameters.
Wrong COM port Click Change COM port and follow the instructions.
Baud rate of parameterisation program and servo
positioning controller is not identical Click Search Baud rates.
Communication of servo positioning controller has
been interfered RESET the servo positioning controller, i.e.
power−off/power−on. After this, click Retry with old
parameters.
Hardware error
Servo positioning controller is not switched on Remove error, then click Retry with old parameters.
Connecting cable has not been plugged in
Connecting cable is broken
Wrong pin assignment for serial connection
Connecting cable is too long Reduce baud rate or use shorter cable.
